This tutorial assumes that the previous tutorial have been completed.
1. Accessing the MikroTik router (WebFig)
- Login in browser at the adress http://192.168.88.1/ with admin user and the proper password.
2. Activating and accessing the MikroTik graphs system
- The RouterOs operating system of the MikroTik equipments allows the activation of statistics for the interfaces traffic, queues (limitation) of bandwidth and hardware resources.
- The access at stored graphs can be secured only for the users of the network based on IP addresses.
- Pentru activarea graficelor de trafic pe intefețe urmează pașii din imaginile următoare.
- For activating the graphs of bandwidth limitations follow the steps from the next images.
- For activating the graphs of hardware resources follow the steps from the next images.
- After a period of at leat 5 minutes, the graphs will begin to be created on the router.
- The graphs can be viewed by accessing the login page of the MikroTik router, from the menu Graphs.
